The official RGNL-45 product table lists several glass families and one double-glazing notation. A controlled order still needs a pane-by-pane schedule, safety basis, coating location and approved revision for every window mark.
Convert the RGNL-45 Glass List into an Order Specification
Rogenilan’s official RGNL-45 Series Aluminum Casement Windows page identifies a 45 mm system, 6063-T5 thermal-break aluminum profile and 1.6 mm aluminum thickness. Its table lists tempered, double or triple tempered, laminated, Low-E, reflective and tinted glass families.
The page also publishes “5 mm + 15Ar + 5 mm” for tempered double glazing. Preserve that source notation in the enquiry and ask for its full written interpretation. Do not infer pane treatment, spacer, gas, coating face, safety classification or project performance from the shorthand alone. The related Casement Windows product category confirms the product family.
RGNL-45 Quick Specs and Glass Approval Controls
| Item | Published RGNL-45 data | Buyer control |
|---|---|---|
| Product identity | RGNL-45 Series Aluminum Casement Windows; the table names an RGNL-45 Thermal Break System Awning Window | Keep the product URL, series and selected opening mode on the glass schedule |
| Width | 45 mm | Require the returned section to identify what this measurement describes |
| Profile | 6063-T5 thermal-break aluminum profile | Coordinate the glazing with the exact offered frame and sash sections |
| Aluminum thickness | 1.6 mm | Ask the supplier to mark where the value applies |
| Glass families | Tempered; double or triple tempered; laminated, Low-E, reflective or tinted | Select one complete make-up for each window mark |
| Glass wording | “Automotive Grade Tempered Glass” is listed | Request the exact proposed glass description and applicable project standard |
| Double-glazing notation | 5 mm + 15Ar + 5 mm | Obtain a pane-by-pane return without silently reinterpreting the source |
| Opening modes | Inward, tilt-and-turn, outward or awning | Check glass weight and hardware suitability for the selected mode and size |
The public product table does not publish maximum glass sizes, pane weights, coating positions, edgework, spacer details, safety classifications, whole-window ratings or a universal compliance standard.
Compare the Published Glass Families
Tempered Glass
The official page lists tempered glass. Define pane thickness, treatment, marking and the applicable safety requirement instead of ordering by family name alone.
Double or Triple Glazing
Use a complete sequence for every pane and cavity. The published 5 mm + 15Ar + 5 mm notation is a quotation reference, not proof of suitability for every unit.
Laminated Glass
Laminated glass is listed as available. State pane thicknesses, interlayer specification, required treatment and which pane of an insulating unit is laminated.
Low-E, Reflective or Tinted
These families are listed, but the page does not identify coating products, colors or faces. Return the exact selection, appearance sample and orientation for approval.
Glass Selection and Approval Sequence
- Issue window marks, dimensions, quantities, opening modes and viewed-side elevations.
- State the required safety, thermal, solar, acoustic, appearance and privacy criteria without inventing unverified RGNL-45 ratings.
- Request a returned pane-by-pane build-up, cavity description, coating location, glass code and applicable evidence.
- Coordinate the proposed make-up with sash size, opening mode, hardware and frame sections.
- Approve the written glass schedule and any required visual or representative sample before production release.
If performance evidence is required, ask that every report or calculation identify the tested or assessed window, size, frame, glass, hardware, installation condition, standard, result and limitation. A glass-only value should not be presented as a whole-window result.
Glass and Quotation Cost Factors
The official page does not publish a fixed price. Quotation changes can follow the window size and quantity, pane thickness, number of panes, laminated make-up, Low-E or reflective selection, tint, edgework, heat treatment, required markings, sample scope, evidence, packaging and destination.
Ask every offer to return the same window schedule and glass-code register. Alternate make-ups, unavailable coatings or proposed substitutions should be listed separately before commercial comparison. Confirm who bears the cost of revised samples, replacement glass and re-inspection if the delivered make-up does not match the approved schedule.
What to Send for an RGNL-45 Glass Quote
- Window marks, dimensions and quantities
- Viewed-side elevations and opening modes
- Complete pane and cavity sequence
- Tempered or laminated treatment requirements
- Low-E, reflective or tint selection and face
- Applicable safety and project criteria
- Required samples, markings and evidence
- Frame finish and appearance coordination
- Packaging and replacement-glass controls
- Destination, delivery basis and target date
Send the marked glass schedule to Rogenilan and request a returned exceptions list with the quotation.
RGNL-45 Glass Specification FAQ
Which glass families are listed for the RGNL-45 casement window?
The official table lists tempered, double or triple tempered, laminated, Low-E, reflective and tinted glass. Each order still needs one exact approved make-up.
What double-glazing notation is published?
The page publishes 5 mm + 15Ar + 5 mm. Keep that source notation visible and ask the supplier to return its complete meaning, treatments and components in writing.
Does the product page prove a whole-window thermal or acoustic rating?
No verified whole-window result is established by the specification table. Request applicable evidence for the exact proposed size, frame, glass, hardware and installation condition.
Can the same glass be used for every opening mode?
Do not assume so. Glass dimensions and weight must be reviewed with the selected inward, tilt-and-turn, outward or awning configuration and its hardware.
What should be frozen before production?
Approve the window schedule, glass codes, pane and cavity sequence, coatings and faces, treatments, markings, opening modes, samples, evidence and controlled revision.
Request an RGNL-45 Glass Specification Review
Share the window schedule, elevations, opening modes, glass criteria, proposed make-ups, finish, quantities and destination. Rogenilan can review a defined RGNL-45 glass package and return the information still needed for approval and quotation.
