RGNL-45 Casement Window China Manufacturer Profile Specs
The official RGNL-45 product table lists a 45 mm width, 6063-T5 thermal-break aluminum profile and 1.6 mm aluminum thickness. A procurement-ready submittal must also show where each value applies on the returned frame and sash sections.
Turn Published Profile Data into an Approvable Submittal
Rogenilan’s official RGNL-45 Series Aluminum Casement Windows page supplies a product-level baseline, while the Casement Windows product category confirms the applicable product family.
For a controlled quotation, do not treat the three headline profile values as a complete fabrication drawing. Ask the returned section set to identify the outer frame, operable sash, thermal-break zone, glazing pocket, opening mode and wall interface for every scheduled window mark.
RGNL-45 Quick Specs and Buyer Controls
| Item | Published RGNL-45 data | Buyer control |
|---|---|---|
| Product identity | RGNL-45 Series Aluminum Casement Windows; the product table names an RGNL-45 Thermal Break System Awning Window | Keep the public product URL and agreed series description on the RFQ and submittal |
| Width | 45 mm | Require the section drawing to show what the listed width measures |
| Profile | 6063-T5 thermal-break aluminum profile | Return the proposed frame and sash sections with material designation |
| Thickness | 1.6 mm aluminum thickness | Mark the members or section locations to which the value applies |
| Glass families | Tempered, double or triple tempered, laminated, Low-E, reflective or tinted | Specify one complete glass make-up for each window mark |
| Listed glazing notation | 5 mm + 15Ar + 5 mm | Ask for a returned glass schedule without reinterpreting the source notation |
| Opening modes | Inward, tilt-and-turn, outward or awning | Show mode, handing and viewed side on every elevation |
| Finish routes | Powder coating, anodized, wooden grain or PVDF coating | State the required process and approved color reference separately |
The public page does not establish universal maximum sizes, corner-joint details, drainage geometry, thermal values, fastening layouts or installation tolerances. These require order-specific drawings or supporting documents.
Four Profile Controls to Compare Before Approval
Section Identity
Give every returned frame, sash, mullion and transom section a reference. Link those references to the window schedule instead of accepting an unmarked profile sheet.
Dimension Mapping
Ask the drawing to locate the published 45 mm width and 1.6 mm thickness. Do not assume one value describes every component or wall interface.
Thermal-Break Construction
The official table identifies a thermal-break profile. Require the supplier’s section return to show the proposed break zone and the exact profile set offered.
Opening-Mode Interface
Inward, tilt-and-turn, outward and awning modes can require different sash, hardware and clearance coordination. Fix the mode for every window mark before approval.
Profile Submittal Approval Sequence
- Issue elevations with window marks, structural openings, viewed side, mode and handing.
- Request marked frame, sash, mullion, transom, glazing and interface sections.
- Check the returned 45 mm width, 6063-T5 designation and 1.6 mm thickness against the quoted product.
- Confirm glass make-up, finish, hardware functions and drainage information for the selected opening mode.
- Freeze one revision for sample, production inspection and shipment-document references.
If a project needs structural, thermal, water, air, acoustic or other performance evidence, define the target and require documents for the exact proposed size, frame, glass, hardware and installation condition. The public product table alone is not that evidence.
Profile and Quotation Cost Factors
The official page does not publish a fixed price. Cost can change with unit size, section set, operable-to-fixed ratio, opening mode, glass build-up, finish, hardware functions, screens, trims, quantities, sample requirements, inspection scope, packing and destination.
For comparable offers, give every bidder the same marked schedule and require a returned section register. Any alternate profile, thickness, glass or opening mode should appear in a separate exceptions list before commercial comparison.
What to Send for an RGNL-45 Profile Quote
- Window schedule with marks, sizes and quantities
- Elevations with viewed side, mode and handing
- Structural opening and wall-build-up details
- Required frame, sash, mullion and transom sections
- Glass make-up and glazing requirements
- Finish process and color reference
- Hardware functions, screens and accessories
- Required reports, drawings and revision register
- Sample, inspection and substitution controls
- Destination, packing and delivery basis
Send the marked profile brief to Rogenilan with the project schedule and required return date.
RGNL-45 Profile FAQ
What profile material is published for the RGNL-45 casement window?
The official product table lists a 6063-T5 thermal-break aluminum profile. The returned submittal should identify the exact frame and sash sections proposed for the order.
Does 45 mm describe the complete installed depth?
The page lists a 45 mm width but does not define every measurement reference. Ask the supplier to mark the value on the returned section drawing before approval.
Where does the published 1.6 mm thickness apply?
The public table states 1.6 mm aluminum thickness but does not map it to every member. Require the proposed sections to identify where the value applies.
Can one profile submittal cover every opening mode?
Do not assume so. Assign inward, tilt-and-turn, outward or awning operation to each window mark and obtain the matching section and hardware return.
What should buyers approve before production?
Approve the marked profile sections, window schedule, opening modes, glass, finish, hardware functions, interfaces, required evidence, sample basis and controlled revision.
Request an RGNL-45 Profile Review
Share the window schedule, elevations, wall details, glass, finish, hardware functions, quantities and destination. Rogenilan can return a profile-based quotation and identify the information still needed before approval.
