RGNL-116 Aluminum Shutter China Manufacturer: Louver and Quote Specifications
Verified profile, louver, glass, pull-rod, opening and finish data for architects, developers, contractors and importers preparing an aluminum shutter enquiry.
What the Official RGNL-116 Shutter Page Confirms
Rogenilan’s official product is the RGNL-116 Thermal Break System Aluminum Shutter. The product table identifies a 116 mm system, a 6063-T5 thermal-break aluminum profile, an aluminum-alloy louver, a shutter-specific pull rod and a flip-open mode. The Rogenilan 2024 catalog also lists the 116 Aluminum Alloy Louvers product.
The page does not publish panel size limits, blade dimensions, free-air area, pull-rod operating limits, drainage details or project-specific performance reports. Those items should be reviewed against the proposed elevation and installation condition before an order is approved.
Verified RGNL-116 Aluminum Shutter Specifications
| Item | Official product-page information | Quote action |
|---|---|---|
| Official product | RGNL-116 Thermal Break System Aluminum Shutter | Use the full series name on the enquiry and approval drawings. |
| System width | 116 mm | Coordinate the frame with the wall, sill, jamb and interior trim. |
| Profile | 6063-T5 thermal-break aluminum profile | Request the proposed frame, panel and mullion sections. |
| Published thickness entry | “1.6 Aluminium Thickness”; unit not stated | Require the factory to state the unit and applicable section in writing. |
| Glass | Single-layer fine frosted glass is listed as available | Show where glass is required and approve its thickness and safety treatment. |
| Middle hollow | Aluminum-alloy louver | Confirm blade profile, pitch, angle and operating arrangement. |
| Hardware | ROGENILAN shutter-specific pull rod | Confirm rod position, operation, access and replacement method. |
| Opening mode | Flip open | Mark hinge side, swing direction and required clearance. |
| Surface treatments | Powder coating, anodized, wood grain and PVDF coating | State the selected treatment and approved color reference. |
| Screen material | Alloy wire mesh | Confirm location, attachment and maintenance access. |
Define Each Component Before Pricing
Louver Assembly
State whether the blades are required in every panel. Ask for blade profile, spacing, control direction and a section drawing because those details are not published on the product page.
Flip-Open Panel
Mark the panel hinge side and swing path on the elevation. Check clearance from sanitary fittings, counters, screens and other interior elements.
Frosted Glass
The page lists single-layer fine frosted glass as available but does not define its location or thickness. Identify glazed areas and required safety treatment in the enquiry.
Alloy Wire Mesh
If a screen is required, show which side it occupies and how it is removed. Coordinate it with the pull rod and flip-open operation.
Louver and Hardware Approval Checks
Start with a dimensioned elevation showing each frame, panel, blade field, glass area and screen. Add the opening direction, pull-rod location and finished-floor level so the supplier can review operation and access. For a white product, provide an exact color reference and approve a physical finish sample; the official page names finish processes but does not publish a standard white code.
Ask for sections through the head, sill and jamb. Confirm how water is managed at the opening, how the frame is fixed, and which perimeter sealants or flashings remain in the installer’s scope. Do not transfer details from a different shutter series without written confirmation.
What Changes the Factory Quote
Compare suppliers against one coordinated schedule. A unit price without the panel, louver, finish and accessory scope is not directly comparable.
- Overall width, height and quantity
- Panel count and mullion layout
- Louver blade field and control
- Flip-open direction and hardware
- Frosted-glass locations and treatment
- Alloy wire mesh scope
- Surface treatment and color sample
- Head, sill and jamb interfaces
- Trims, anchors, flashings and sealants
- Packaging, destination and delivery terms
Information to Send for an RGNL-116 Quote
Send a complete enquiry package so the China manufacturer can review one defined shutter configuration.
- Project location and building type
- Dimensioned shutter schedule
- Interior and exterior elevations
- Panel and mullion arrangement
- Hinge side and opening direction
- Louver blade and control requirements
- Frosted-glass locations and specification
- Finish process and color reference
- Screen and accessory requirements
- Wall, sill, head and jamb details
- Required reports or calculations
- Destination, Incoterm and target date
FAQ
Is the RGNL-116 an official aluminum shutter product?
Yes. Rogenilan’s official page names it the RGNL-116 Thermal Break System Aluminum Shutter, and the 2024 catalog lists 116 Aluminum Alloy Louvers.
What louver details are published?
The product table identifies an aluminum-alloy louver in the middle hollow and a shutter-specific pull rod. It does not publish blade profile, pitch, angle or operating limits, so these require drawing approval.
Is the aluminum thickness confirmed as 1.6 mm?
No. The page says “1.6 Aluminium Thickness” but does not state a unit. The quotation and section drawing should identify the unit and the profile section to which it applies.
Can a white finish be ordered?
The official page lists powder coating, anodized, wood grain and PVDF coating, but it does not publish a standard white code. Send the required white color reference and obtain written and sample approval.
What should importers approve before production?
Approve dimensions, panel layout, louver details, opening direction, pull-rod position, glass, screen, finish sample, sections, installation interfaces, packaging and any required performance documents.
Request an RGNL-116 Aluminum Shutter Quote
Send Rogenilan your shutter schedule, elevations, panel layout, louver requirements, glass, finish, screen, quantity and destination. The factory can review the RGNL-116 configuration against a defined project scope.
