RGNL-110 Casement Window China Supplier Quote Requirements
A useful RGNL-110 quotation should connect every price line to a window mark, approved configuration and stated supply boundary. Buyers can then compare the base scope, priced options, exclusions and commercial assumptions without guessing what each offer includes.
What a Comparable RGNL-110 Quote Must Show
The official RGNL-110 Series Broken Bridge Casement Windows page identifies the frame basis, listed glass and finish families, outward and awning opening modes, and alloy wire mesh. It does not publish one universal project configuration.
For a comparable return, issue one revision-controlled window schedule and require the quote to use the same marks, dimensions, quantities and options. The supplier should separate the base configuration from alternatives, identify deviations and exclusions, and state where the supply and delivery responsibilities begin and end.
RGNL-110 Quick Specs and Quote Controls
| Item | Published RGNL-110 data | Required quote response |
|---|---|---|
| Product basis | RGNL-110 Series Broken Bridge Casement Windows | Keep the exact series and product URL on the offer |
| Frame basis | 110 mm system; 6063-T5 thermal-break aluminum; listed 1.6 mm thickness | Reference the proposed section drawings and state where the listed thickness applies |
| Glass families | Tempered double or triple glazing; laminated, Low-E, reflective and tinted choices | Price one complete build-up per mark and list alternatives separately |
| Published glass notation | 5 mm + 15Ar + 5 mm | Define each pane and cavity notation in the returned glass schedule |
| Finish choices | Powder coating, anodized, wood grain and PVDF | Quote the specified finish and isolate option-price changes |
| Operation and screen | Outward opening, awning opening and alloy wire mesh are listed | Show opening mode, handing and screen scope for each mark |
The public page does not establish project-specific performance values, size limits, minimum order, lead time or unit prices. Request those items for the submitted configuration.
Use a Four-Part Quotation Structure
1. Base Scope
List each window mark, quantity, dimensions, opening mode, glass code, finish and included screen. Subtotals should follow the same schedule used on the drawings.
2. Priced Options
Place glass, finish, screen, accessory, sample or spare-part alternatives on separate lines. Identify whether each option adds to or replaces the base scope.
3. Deviations and Exclusions
Record every proposed substitution, unresolved dimension, omitted accessory, document limitation and installation exclusion. Silence should not be treated as acceptance.
4. Commercial Basis
State currency, validity, payment stages, production timing basis, packing scope, delivery basis, destination and taxes or charges included or excluded.
Separate Outward and Awning Quote Lines
Side-hinged outward-opening units and top-hinged awning units should not share one generic price line. Their sash arrangement, handing, operating hardware, projection, screen interface and installation clearances may differ.
Assign a mark to every opening. The returned elevation should show the interior or exterior viewing direction, hinge location, handle position and opening arc. If one elevation combines fixed and operable lites, ask the quote to identify the operable part rather than pricing only the overall frame size.
Normalize Options Before Comparing Offers
Prepare a bid-comparison sheet using identical columns for frame basis, glass code, finish, opening, screen, accessories, required documents, inspection, packing and delivery. Transfer every supplier response into that sheet; do not compare only the total.
The official Casement Windows product category confirms the product family. Project drawings and the returned schedules must define the exact order.
RGNL-110 Price Factors to Record
Quotation value can change with unit dimensions, quantity by mark, fixed and operable layout, glass build-up, finish, hardware functions, screen scope, trims, installation accessories, samples, required technical documents, inspection, spares, crate design and delivery basis.
Ask for a separate value when an option changes. This preserves the original base offer and makes later approvals traceable. No public price, discount, minimum order, freight rate or standard lead time is claimed here.
RFQ Package and Required Return
- Project location, destination and required standards
- Window marks, elevations, dimensions and quantities
- Outward or awning mode and handing
- Complete glass build-up for every mark
- Finish type, color reference and sample requirement
- Hardware functions, screen and accessory scope
- Performance criteria and requested supporting records
- Drawing, sample and inspection stages
- Packing, labeling, spares and delivery basis
- Quote validity, timing basis and payment stages
Require the return to include the priced schedule, marked drawings, proposed material and glass schedules, option table, deviation list, exclusions, packing statement and commercial terms.
RGNL-110 Quotation FAQ
What facts are verified for the RGNL-110 frame?
The official page lists a 110 mm system, 6063-T5 thermal-break aluminum profile and 1.6 mm aluminum thickness. Ask the returned section drawing to identify where the listed thickness applies.
Should 5 mm + 15Ar + 5 mm be used as the default glass?
No. It is a published notation, not a universal project default. The buyer should approve one complete glass build-up for each window mark.
How should outward and awning units be quoted?
Use separate marks and price lines. Show the opening mode, handing, handle position, projection, screen and applicable accessories for each unit.
How can buyers compare finish options?
Specify one base finish and color reference, then ask for powder coating, anodized, wood-grain or PVDF alternatives only where relevant. Keep each price adjustment separate.
What should not be assumed from a total price?
Do not assume identical glass, hardware, screens, accessories, documents, packing or delivery scope. Compare the itemized schedule, deviations and exclusions before comparing totals.
Request a Structured RGNL-110 Quote
Send Rogenilan the marked window schedule, drawings, glass, finish, opening modes, quantities, destination and required return format. The quotation can then be issued against one controlled RGNL-110 scope.
