RGNL-110 Sliding Door China Manufacturer Quote Requirements
A comparable RGNL-110 quotation needs more than an opening size. Overseas buyers should issue one controlled door schedule that fixes the track layout, unit dimensions, quantities, glass build-up, finish, hardware functions, packing destination and delivery basis before comparing a China manufacturer’s return.
Start With a Verifiable Product Baseline
The official RGNL-Aluminium 110 Series Soundproof Sliding Doors page provides the public specification baseline used here. The Sliding Doors product category confirms its product taxonomy.
The page publishes two track widths, an 82 mm source-labelled viewable area, 6063-T5 thermal-break aluminum, 1.6 mm aluminum thickness, several glass families, one insulating-glass notation and three surface-treatment phrases. It does not publish a universal price, fabrication size range, order quantity, lead time, packing method or delivery term. Those items must be returned for the actual project rather than assumed.
RGNL-110 Quick Specs for the RFQ
| RFQ field | Published product data | Buyer input still required |
|---|---|---|
| Product identity | RGNL-Aluminium 110 Series Soundproof Sliding Doors | Door marks, drawing revision and quantities |
| Track layout | Two-track 110 mm; three-rail 175 mm | Selected track and panel arrangement for each opening |
| Profile | 6063-T5 thermal-break aluminum; 1.6 mm aluminum thickness | Approved section drawing and interface dimensions |
| Viewable-area value | 82 mm, using the source page’s label | Confirm where the value applies on the returned drawing |
| Glass families | Tempered, double or triple tempered, laminated, Low-E, reflective or tinted | Full pane build-up, safety treatment and coating location |
| Published glazing notation | Double glazing tempered, 5 mm + 15Ar + 5 mm | Written confirmation of cavity, gas and applicable project requirements |
| Surface treatment | “Powder Coating, Anodized Wooden Grain, PVDF Coating” | Chosen route, color, texture, gloss and approved sample |
The table preserves source wording where the original grouping is unclear. It does not infer acoustic, thermal, wind, water, air or certification results.
Compare Configuration Before Price
Two-track quotation
Use the published 110 mm two-track value only when that layout is selected. Show every fixed and sliding panel on the elevation, identify the interior and exterior sides, and mark the required opening direction. A total opening width alone cannot define the panel arrangement.
Three-rail quotation
The public table lists a 175 mm three-rail option. Keep it as a separate line item because the track, panel arrangement, fabrication scope and packing volume may differ from a two-track unit. Ask the returned drawing to show the rail sequence and panel overlap.
Define Each Opening, Not Just the Series
Assign a unique mark to every door type. For each mark, state finished opening width and height, quantity, track layout, panel count, opening direction, sill condition and adjacent construction. Add the complete glass build-up and finish reference. If insect screens, special thresholds, drainage interfaces or access restrictions are required, identify them as project requests and obtain written confirmation; the public specification table does not establish them as standard.
Use white only as a requested finish when that is the project preference. A white illustrative image is not evidence that white is the default order color. Approval should rely on a named physical sample linked to the purchase documents.
What Changes the Quotation
The final amount can change with dimensions, quantities, two-track or three-rail construction, panel layout, glass build-up, finish route, hardware functions, sample work, drawing revisions, inspection scope, protective packing, destination and delivery term. The official page does not publish one price that can represent all combinations.
Request an itemized return showing unit description, quantity, inclusions, exclusions, proposed substitutions, packing basis and quotation validity. Treat any performance, certification or market-compliance requirement as a document request that must be supported for the quoted configuration.
Quotation Checklist for Overseas Buyers
- Project country, site and applicable requirements
- Door schedule and drawing revision
- Opening dimensions, marks and quantities
- Two-track or three-rail selection
- Panel layout and opening direction
- Complete glass build-up
- Finish route and approved color sample
- Required hardware functions
- Threshold and installation interfaces
- Inspection and document requirements
- Packing and unloading constraints
- Destination and delivery basis
Send the controlled schedule to Rogenilan and request a written return against the same revision.
RGNL-110 Quotation FAQ
Does RGNL publish a standard RGNL-110 price?
The official product page does not publish a universal price. A project quotation needs dimensions, quantities, configuration, glass, finish, hardware functions, packing and delivery inputs.
Which track widths are listed?
The public specification table lists 110 mm for two-track construction and 175 mm for three-rail construction.
What glass is available?
The page lists tempered, double or triple tempered, laminated, Low-E, reflective and tinted glass families. It also displays a 5 mm + 15Ar + 5 mm double-glazing notation. The complete order build-up still requires written confirmation.
Can a buyer request a white finish?
Yes, white can be submitted as a project finish request, but the public table does not establish one universal white color. Specify the color reference, texture, gloss and physical-sample approval method.
What should be checked before comparing China manufacturer quotations?
Confirm that every return uses the same schedule revision, track layout, panel arrangement, dimensions, quantities, glass, finish, hardware functions, packing scope and delivery basis.
Request an RGNL-110 Project Quotation
Submit one door schedule with dimensions, quantities, track layout, panel arrangement, glass, finish, hardware functions and delivery destination.
