RGNL-108 Micro-Ventilation Window China Exporter Import Specs
Import buyers can use the official RGNL-108 product facts as a quotation baseline: 108 mm track width, 6063-T5 thermal-break aluminum, 2.2 mm aluminum thickness, listed glazing options and double inward opening. Before ordering from a China exporter, connect that baseline to an opening schedule, item marks, packing references and a document index for the actual shipment.
Lock the Product Identity Before Import Pricing
The official RGNL micro-ventilation energy-saving inward-opening window page identifies the series and its published technical baseline. Use the exact product name, system width, opening mode and selected glass and finish on the RFQ. This prevents a general “micro-ventilation window” description from being priced against a different configuration.
Assign every project opening an item mark. The same mark should appear on the size schedule, quotation, packing reference and shipment document list. Dimensions must state whether they are structural opening, finished opening or frame size.
Verified Quick Specs and Import Actions
| Item | Official Product Information | Import Specification Action |
|---|---|---|
| Product identity | Micro ventilation series energy-saving inward-opening window | Use this identity with a unique project item mark and quantity. |
| Width | 108 mm track width | Record it as system information; do not substitute it for wall or package dimensions. |
| Profile | 6063-T5 thermal-break aluminum profile | Request the offered section return and identify where the published thickness applies. |
| Aluminum thickness | 2.2 mm | Keep the value linked to the quoted RGNL-108 configuration. |
| Listed glass | 5 mm + 15Ar + 5 mm double-glazed tempered build-up | Confirm one complete project build-up, including treatment and coating requirements. |
| Other listed glass | Double or triple tempered, laminated, Low-E, reflective and tinted families | Treat these as choices, not as one combined specification. |
| Opening | Double inward opening | State the interior view, handing and handle position for each item mark. |
| Surface treatments | Powder coating, anodized, wood grain and PVDF coating | Select one finish route and provide a color or sample reference. |
Use Four Import-Control Records
Item Schedule
List opening mark, frame size, quantity, handing, glass, finish, accessories and destination area. Freeze a revision before the final quotation.
Quote Exception Log
Require the exporter to identify substitutions, exclusions, buyer-supplied items and unconfirmed details instead of leaving differences inside general notes.
Packing and Marking Return
Request the proposed package reference, item marks, package dimensions, gross and net weight fields, handling marks and protection method for approval.
Shipment Document Index
Agree which commercial, packing, transport and product records are required, who prepares each record and when the buyer must approve it.
Match the Import Specification to the Order
For repeated rectangular windows, group only openings that share the same frame size, sash layout, glass, finish and accessories. Separate item marks when handing, handle position or installation interface changes. Bay, corner or asymmetrical arrangements should have their own approved geometry and packing references rather than being inferred from a standard rectangular window.
Before accepting an offer, reconcile the item schedule total with the quotation quantity. Then compare the exporter’s returned product configuration, exclusions and packing assumptions against the same revision.
Price and Quotation Factors
A meaningful China export quotation needs the same scope from every bidder. Price can change with:
- Frame size, quantity and repeated item types
- Fixed and inward-opening sash arrangement
- Selected glass build-up and treatment
- Finish route and color reference
- Hardware functions and accessories
- Screens, trims and sill components
- Required samples and technical returns
- Packing protection and package limits
- Destination, delivery term and shipping scope
- Installation materials and site responsibility
Information to Send with the Import RFQ
Send the project location, opening schedule, frame sizes, quantities, interior-view elevations, handing, handle positions, glass build-up, finish and color, screen and accessory requirements, wall interfaces, installation responsibility, destination, delivery term and any package size or handling restrictions.
Ask the exporter to return the offered product identity, profile sections, glass and finish schedule, hardware functions, itemized price, exceptions, sample requirements, production approval points, proposed packing and marking information, shipment document index and delivery scope. Values that depend on the final order, including package size and weight, should remain subject to the approved packing return rather than being estimated from catalog data.
RGNL-108 Window Import FAQ
Which RGNL-108 facts are verified?
The official product information lists a 108 mm track width, 6063-T5 thermal-break aluminum profile, 2.2 mm aluminum thickness, published glass families, a 5 mm + 15Ar + 5 mm build-up, four surface-treatment routes and double inward opening.
Is the 108 mm width a packing dimension?
No. It is listed as track width. Package dimensions and weights depend on final window sizes, quantities, accessories and the approved packing arrangement.
Which shipment documents should an importer request?
The required set depends on the contract, destination and transport method. Put the required commercial, packing, transport and product records into a document index and confirm responsibility and timing with the exporter.
When should packing marks be approved?
Approve the format after item marks and quantities are frozen, then review the exporter’s returned package references before shipment. The marks should reconcile with the order schedule and packing list.
Request an RGNL-108 Import Quotation
Send the marked opening schedule, selected glass and finish, quantities, destination and delivery scope. Request one technical and commercial return that connects the verified RGNL-108 product baseline to the exact order and packing references.
