RGNL Aluminum Lift-and-Slide Door China Supplier Price Factors
An RGNL lift-and-slide door quotation changes with the selected track, panel map, unit dimensions, glass, finish and delivery scope. Buyers should define those inputs before comparing a China supplier’s price, because a headline area rate cannot show whether two returns describe the same door.
Price Starts with One Controlled Door Definition
The official RGNL-Aluminum Lift And Slide Doors page identifies an aluminum thermal-break heavy-duty lift-and-slide door. Its current taxonomy is the Sliding Doors product category.
The published table supplies configuration choices, not a fixed sales price. A useful RFQ should tie every door mark to one opening size, track arrangement, panel movement, glazing build-up, finish and supply boundary. The supplier can then show a base return, option changes and exclusions against the same revision.
RGNL Lift-and-Slide Door Quick Specs
| Specification | Published product data | Quotation control |
|---|---|---|
| Series | Aluminum thermal-break heavy-duty lift-and-slide doors | Use the exact product and quotation revision |
| Track widths | Two-track 139 mm; three-rail 208 mm | Price the selected track and panel map |
| Profile | 6063-T5 thermal-break aluminum profile | Return the quoted head, jamb and sill sections |
| Aluminum thickness | 2.0 mm | Keep the value linked to this product |
| Glass families | Tempered, double or triple tempered, laminated, Low-E, reflective or tinted | State one complete build-up for each door mark |
| Published notation | Double glazing tempered, 5 mm + 15Ar + 5 mm | Request written definitions before pricing comparison |
| Panel layouts | Two tracks with two or four panels; three tracks with three or four panels | Show fixed, active and sliding panels |
| Surface treatments | Powder coating, anodized, wood grain or PVDF coating | Use an approved finish reference |
No current unit price, minimum order, lead time, freight rate or performance value is stated here. Those items require a project-specific written quotation or supporting document.
Six Factors That Change the Quoted Scope
1. Track and Panel Layout
The 139 mm two-track and 208 mm three-rail options are different configurations. Panel count, active-panel location and travel direction should be fixed before comparison.
2. Unit Dimensions and Quantity
Door marks, measured width and height, quantities and repeated sizes define the fabrication schedule. Do not request one area rate without the opening list.
3. Complete Glass Build-Up
The official page lists several glass families. Pane sequence, heat treatment, laminated layer, coating, tint and cavity details must be returned as one priced assembly.
4. Surface Treatment
Powder coating, anodized, wood grain and PVDF coating are listed routes. Quote one selected route, color reference and sample requirement instead of an undefined standard finish.
5. Approval and Inspection Scope
Define required drawings, finish or glass samples, pre-production approval and inspection records. These are commercial scope items and should be shown as included or excluded.
6. Packing and Delivery Boundary
Ask for protection, package identification, delivery destination and named delivery basis. Door supply should be separated from freight, local handling, installation and surrounding construction.
Normalize the Quotation Before Comparing Price
Put every supplier return into the same comparison sheet. Record the door total, currency, quantity basis, included frame and panels, glass, finish, accessories, drawings, samples, inspection, packing, delivery boundary, taxes or duties where applicable, exclusions, alternatives and quotation validity.
Require each deviation to reference the affected door mark. An alternative track, glass family or finish should not be hidden inside a revised total. This makes the commercial effect visible without assuming that a higher or lower price represents the same configuration.
Choose the Configuration Before Requesting a Final Price
- Confirm the opening schedule, quantities and viewing side.
- Select the 139 mm two-track or 208 mm three-rail arrangement.
- Number all panels and identify their movement.
- Define the complete glass build-up and required evidence.
- Approve the finish route, color reference and sample process.
- State drawing, inspection, packing and delivery requirements.
- Issue one RFQ revision and request a marked return.
The final choice should be checked against the project’s design, code, exposure, access and installation responsibilities. The public product table does not replace project-specific engineering or compliance review.
RFQ Inputs for a Product-Specific Price
- Project location and delivery destination
- Door schedule with widths, heights and quantities
- Interior view and panel movement diagram
- 139 mm two-track or 208 mm three-rail choice
- Complete glass build-up for each door type
- Finish route, color and sample reference
- Required head, jamb and sill drawings
- Accessories and loose-item schedule
- Approval and inspection requirements
- Protection, packing and package marks
- Supply, freight and installation boundaries
- Currency, delivery basis and quotation validity
Send the controlled RFQ to Rogenilan for a marked product-specific return.
RGNL Lift-and-Slide Door Price FAQ
Does Rogenilan publish a standard lift-and-slide door price?
No current standard price is stated in the verified product table. A quotation needs the door schedule, configuration, glass, finish and supply scope.
Why can a three-rail quote differ from a two-track quote?
The verified track widths and panel arrangements differ. The selected configuration changes the product definition, so both returns should be compared against the same panel map and scope.
Is glass included in every quoted door price?
That should be confirmed in the written return. The official page lists several glass families, but a comparable quote needs one complete build-up and clear inclusion status.
Which finish options appear on the product page?
The structured table lists powder coating, anodized, wood grain and PVDF coating. Ask the quotation to identify the selected route, color reference and sample requirement.
How should overseas buyers compare two quotations?
Use the same drawings, quantities, track and panel layout, glass, finish, accessories, documents, packing and delivery boundary. Record every exclusion and alternative separately.
Request an RGNL Lift-and-Slide Door Quote
Share the door schedule, track choice, panel map, glass, finish, approval documents, packing and delivery boundary. Rogenilan can return a quotation against one controlled product definition.
